1,550,000
  • Bảo hành: 36 tháng
  • VAT: Đã bao gồm VAT
Quà khuyến mãi

Giao hàng tận nơi
Thanh toán khi nhận hàng
Đổi trả trong 5 ngày
Không được đổi trả với lý do "không vừa ý"
36 tháng bằng hóa đơn mua hàng
Bảo hành chính hãng toàn quốc
Hotline: 19002074 Ấn Phím 6
PROCESSOR
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
CHIPSET1
Intel® H310 Chipset
MEMORY
2 x DDR4 memory slots, support up to 32GB
Supports DDR4 2666/ 2400/ 2133 MHz (by JEDEC)1
Supports DDR4 2666/ 2400/ 2133 MHz (by XMP OC)1
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
1. 2666 MHz for I7 and I5 processors only.
SLOTS
1 x PCIe 3.0 x16 slot
2 x PCIe 2.0 x1 slots
ONBOARD GRAPHICS
1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI™ port, supports a maximum resolution of 4096x2160@30H
*No Display support when using the Processor model with suffix “F”
STORAGE
Intel® H310 Chipset
4 x SATA 6Gb/s ports
o Supports Intel® Rapid Storage Technology
USB
Intel® H310 Chipset
4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
AUDIO
Realtek® ALC887 Codec
7.1-Channel High Definition Audio
LAN
1 x RTL8111H Gigabit LAN controller
INTERNAL CONNECTORS
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
1 x Clear CMOS jumper
2 x Front panel connectors
1 x Serial port connector
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Front panel audio connector
1 x 4-pin CPU fan connector
1 x 4-pin system fan connector
BACK PANEL PORTS
1. PS/2 Combo Port
2. VGA Port
3. HDMI Port
4. USB 3.1 Gen1
5. LAN Port
6. HD Audio Connectors
7. USB 2.0 Port
8. DVI-D Port
9. USB 2.0 Port

DIMENSIONS
8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
m-ATX Form Factor
MOUNTING
6 mounting holes
OPERATING SYSTEM
Support for Windows® 10 64-bit

Bảo hành 36 tháng
VAT Đã bao gồm VAT
PROCESSOR
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
CHIPSET1
Intel® H310 Chipset
MEMORY
2 x DDR4 memory slots, support up to 32GB
Supports DDR4 2666/ 2400/ 2133 MHz (by JEDEC)1
Supports DDR4 2666/ 2400/ 2133 MHz (by XMP OC)1
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
1. 2666 MHz for I7 and I5 processors only.
SLOTS
1 x PCIe 3.0 x16 slot
2 x PCIe 2.0 x1 slots
ONBOARD GRAPHICS
1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI™ port, supports a maximum resolution of 4096x2160@30H
*No Display support when using the Processor model with suffix “F”
STORAGE
Intel® H310 Chipset
4 x SATA 6Gb/s ports
o Supports Intel® Rapid Storage Technology
USB
Intel® H310 Chipset
4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
AUDIO
Realtek® ALC887 Codec
7.1-Channel High Definition Audio
LAN
1 x RTL8111H Gigabit LAN controller
INTERNAL CONNECTORS
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
1 x Clear CMOS jumper
2 x Front panel connectors
1 x Serial port connector
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Front panel audio connector
1 x 4-pin CPU fan connector
1 x 4-pin system fan connector
BACK PANEL PORTS
1. PS/2 Combo Port
2. VGA Port
3. HDMI Port
4. USB 3.1 Gen1
5. LAN Port
6. HD Audio Connectors
7. USB 2.0 Port
8. DVI-D Port
9. USB 2.0 Port

DIMENSIONS
8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
m-ATX Form Factor
MOUNTING
6 mounting holes
OPERATING SYSTEM
Support for Windows® 10 64-bit
