·         CPU

1.     Support for 8^th Generation Intel^® Core™ i7 processors/Intel^® Core™ i5 processors/ Intel^® Core™ i3 processors/Intel^®Pentium^® processors/Intel^® Celeron^® processors in the LGA1151 package

2.     L3 cache varies with CPU

(Please refer "CPU Support List" for more information.)

·         Chipset

1.     Intel^® B360 Express Chipset

·         Memory

1.     4 x DDR4 DIMM sockets supporting up to 64 GB of system memory

2.     Dual channel memory architecture

3.     Support for DDR4 2666/2400/2133 MHz memory modules

4.     Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

5.     Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

6.     Support for Extreme Memory Profile (XMP) memory modules
* To support 2666 MHz or XMP memory, you must install an 8^th Generation Intel^® Core™ i7/i5 processor.

(Please refer "Memory Support List" for more information.)

·         Onboard Graphics

Integrated Graphics Processor-Intel^® HD Graphics support:

1.     1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

2.     1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.

3.     1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.2.

Support for up to 3 displays at the same time
Maximum shared memory of 1 GB

·         Audio

1.     Realtek^® ALC887 codec

2.     High Definition Audio

3.     2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

4.     Support for S/PDIF Out

·         LAN

1.     Realtek^® GbE LAN chip (10/100/1000 Mbit)

·         Expansion Slots

1.     1 x PCI Express x16 slot, running at x16
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

2.     1 x PCI Express x4 slot

3.     1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)

·         Storage Interface

Chipset:

1.     1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)

2.     6 x SATA 6Gb/s connectors

Intel^® Optane™ Memory Ready

·         USB

Chipset:

1.     6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

2.     6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

·         Internal I/O Connectors

1.     1 x 24-pin ATX main power connector

2.     1 x 8-pin ATX 12V power connector

3.     1 x CPU fan header

4.     2 x system fan headers

5.     1 x RGB LED strip header

6.     1 x M.2 Socket 3 connector

7.     6 x SATA 6Gb/s connectors

8.     1 x front panel header

9.     1 x front panel audio header

10.                                                1 x S/PDIF Out header

11.                                                1 x USB 3.1 Gen 1 header

12.                                                2 x USB 2.0/1.1 headers

13.                                                1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

14.                                                1 x serial port header

15.                                                1 x parallel port header

16.                                                1 x Clear CMOS jumper

·         Back Panel Connectors

1.     1 x PS/2 keyboard/mouse port

2.     1 x D-Sub port

3.     1 x DVI-D port

4.     1 x HDMI port

5.     4 x USB 3.1 Gen 1 ports

6.     2 x USB 2.0/1.1 ports

7.     1 x RJ-45 port

8.     3 x audio jacks

·         I/O Controller

1.     iTE^® I/O Controller Chip

·         H/W Monitoring

1.     Voltage detection

2.     Temperature detection

3.     Fan speed detection

4.     Overheating warning

5.     Fan fail warning

6.     Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.

·         BIOS

1.     2 x 128 Mbit flash

2.     Use of licensed AMI UEFI BIOS

3.     Support for DualBIOS™

4.     PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

·         Unique Features

1.     Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
3D OSD
@BIOS
AutoGreen
Cloud Station
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
Platform Power Management
RGB Fusion
Smart Backup
Smart Keyboard
Smart TimeLock
Smart HUD
System Information Viewer
USB Blocker
V-Tuner

2.     Support for Q-Flash

3.     Support for Xpress Install

·         Bundle Software

1.     Norton^® Internet Security (OEM version)

2.     Realtek 8118 Gaming LAN bandwidth Control Utility

·         Operating System

1.     Support for Windows 10 64-bit

·         Form Factor

1.     Micro ATX Form Factor; 22.6cm x 20.5cm
