Product number

9TY84AA

Display panel type

TN

Viewable image area (diagonal)

18.5"

Panel active area (W x H)

409.8 x 230.4 mm

Resolution

WXGA (1366 x 768)

Aspect ratio

16:9

Brightness (typical)

200 nits

Contrast ratio (typical)

600:1 static

Response times

5ms on/off

Pixel pitch

0.3 mm

Display features

Anti-glare; Low blue light mode

User controls

Brightness; Contrast; Exit; Information; Management; Menu; Power; Image; Color

Signal interface/performance

1024 x 768; 1280 x 720; 1366 x 768; 640 x 480; 720 x 400; 800 x 600

Interface

VGA

Display Input Type

1 VGA

VESA mount

100 mm x 100 mm (bracket included)

Physical security

Security lock-ready

Input voltage

Input voltage 100 to 240 VAC

Power consumption

10 W (maximum), 9 W (typical), 0.5 W (standby)

Dimensions With Stand (W x D x H)

44.14 x 15.7 x 34.58 cm

Dimensions (W x D x H)

44.14 x 5.07 x 27.78 cm

Weight

2.45 kg
