6,450,000
  • Bảo hành: 36 tháng
  • VAT: Đã bao gồm VAT
Quà khuyến mãi

Giao hàng tận nơi
Thanh toán khi nhận hàng
Đổi trả trong 14 ngày
Không được đổi trả với lý do "không vừa ý"
36 tháng bằng hóa đơn mua hàng
Bảo hành chính hãng toàn quốc
Hotline: HOTLINE 19002074 ẤN PHÍM 6

     Intel® Xeon® Processor E3-1230 v6 (8M Cache, 3.50 GHz)
Code Name  Kaby Lake
Essentials
Vertical Segment Server
Processor Number E3-1230V6
Status Launched
Launch Date Q1'17
Lithography 14 nm
Recommended Customer Price $250.00 - $261.00
Performance
# of Cores 4
# of Threads 8
Processor Base Frequency 3.50 GHz
Max Turbo Frequency 3.90 GHz
Cache 8 MB
Bus Speed 8 GT/s DMI3
TDP 72 W
VID Voltage Range 0.55V-1.52V
Supplemental Information
Embedded Options Available No
Conflict Free Yes
Datasheet Link
Memory Specifications
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2400, DDR3L-1866
Max # of Memory Channels 2
Max Memory Bandwidth 37.5 GB/s
ECC Memory Supported   ‡ Yes
Graphics Specifications
Processor Graphics ‡ None
Graphics Output N/A
4K Support No
Max Resolution (HDMI 1.4)‡ N/A
Max Resolution (DP)‡ N/A
Max Resolution (eDP - Integrated Flat Panel)‡ N/A
Max Resolution (VGA)‡ N/A
DirectX* Support N/A
OpenGL* Support N/A
Intel® Quick Sync Video No
Intel® InTru™ 3D Technology No
Intel® Clear Video HD Technology No
Intel® Clear Video Technology No
# of Displays Supported ‡ 0
Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations ‡ 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes 16
Package Specifications
Sockets Supported FCLGA1151
Max CPU Configuration 1
Package Size 37.5mm X 37.5mm
Low Halogen Options Available See MDDS
Advanced Technologies
Intel® Optane™ Memory Supported ‡ Yes
Intel® Turbo Boost Technology 2.0
Intel® vPro™ Technology ‡ Yes
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® TSX-NI Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions SSE4.1/4.2, AVX 2.0
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes
Intel® Memory Protection Extensions (Intel® MPX) Yes
OS Guard Yes
Intel® Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
Intel® Device Protection Technology with Boot Guard Yes
Bảo hành 36 tháng
VAT Đã bao gồm VAT

     Intel® Xeon® Processor E3-1230 v6 (8M Cache, 3.50 GHz)
Code Name  Kaby Lake
Essentials
Vertical Segment Server
Processor Number E3-1230V6
Status Launched
Launch Date Q1'17
Lithography 14 nm
Recommended Customer Price $250.00 - $261.00
Performance
# of Cores 4
# of Threads 8
Processor Base Frequency 3.50 GHz
Max Turbo Frequency 3.90 GHz
Cache 8 MB
Bus Speed 8 GT/s DMI3
TDP 72 W
VID Voltage Range 0.55V-1.52V
Supplemental Information
Embedded Options Available No
Conflict Free Yes
Datasheet Link
Memory Specifications
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2400, DDR3L-1866
Max # of Memory Channels 2
Max Memory Bandwidth 37.5 GB/s
ECC Memory Supported   ‡ Yes
Graphics Specifications
Processor Graphics ‡ None
Graphics Output N/A
4K Support No
Max Resolution (HDMI 1.4)‡ N/A
Max Resolution (DP)‡ N/A
Max Resolution (eDP - Integrated Flat Panel)‡ N/A
Max Resolution (VGA)‡ N/A
DirectX* Support N/A
OpenGL* Support N/A
Intel® Quick Sync Video No
Intel® InTru™ 3D Technology No
Intel® Clear Video HD Technology No
Intel® Clear Video Technology No
# of Displays Supported ‡ 0
Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations ‡ 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes 16
Package Specifications
Sockets Supported FCLGA1151
Max CPU Configuration 1
Package Size 37.5mm X 37.5mm
Low Halogen Options Available See MDDS
Advanced Technologies
Intel® Optane™ Memory Supported ‡ Yes
Intel® Turbo Boost Technology 2.0
Intel® vPro™ Technology ‡ Yes
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® TSX-NI Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions SSE4.1/4.2, AVX 2.0
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes
Intel® Memory Protection Extensions (Intel® MPX) Yes
OS Guard Yes
Intel® Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
Intel® Device Protection Technology with Boot Guard Yes
